The V200 Tempered Glass Mid-Tower Chassis is a perfect upgrade for someone looking to give their rig a facelift. It features one preinstalled 120mm standard fan at the rear, a durable tempered glass window, clear acrylic front window and a handy PSU cover. The V200 TG is one of our simple and sleek designed cases which is built for high-end hardware and custom system designs.
- The image is for reference only.
Tt LCS Certified is a Thermaltake exclusive certification applied to only products that pass the design and hardcore enthusiasts standards that a true LCS chassis should be held to. The Tt LCS certification was created so that we at Thermaltake can designate to all power users which chassis have been tested to be best compatible with extreme liquid cooling configurations to ensure you get the best performance from the best features and fitment.
The V200 TG comes with a full length power supply cover that provides plenty of space to implement cable management, while keeping airflow clear for your hard drives and PSU.
The 4mm tempered glass window on the side of the V200TG is built to be more durable, scratch resistant, and transparent for an advanced view of your hardware.
A handy magnetic fan filter on the top simply attaches for easy dust filtration and particulate protection. At the base of the chassis, additional fan filters provide excellent protection against both dirt and dust.
One 3.0 USB and two 2.0 USB ports on the top-front panel to grant direct access when needed.
(Water 3.0 and Floe series)
|Performer||Pro||120 Series||240 Series||140 Series||280 Series|
|PURE FAN Series||●||●||-|
|Riing FAN Series||●||●||-|
V200 TG (2020 Version)
|Case Type||Middle tower|
|Dimension (H x W x D)||446 x 204 x 439 mm
(17.6 x 8.3 x 17.3 inch)
447 x 217 x 432 mm
(17.6 x 8.54 x 17 inch)
|Net Weight||6.5 kg / 14.33 lb
6.06 kg / 13.36 lb
|Side Panel||4mm Tempered Glass x 1|
|Color||Exterior & Interior : Black|
|Cooling System||Rear (exhaust) :
120 x 120 x 25 mm fan (1000rpm, 16dBA)
3 x 2.5“
2 x 3.5”
2 x 3.5” or 2 x 2.5“
2 x 2.5”
|Motherboards||6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)|
|I/O Port||USB 3.0 x 1, USB 2.0 x 2, HD Audio x 1, R Button x 1|
|PSU||Standard PS2 PSU (optional)|
3 x 120mm, 2 x 140mm
2 x 120mm, 2 x 140mm
1 x 120mm
|Radiator Support||Front: 1 x 240mm, 1 x 280mm
Rear: 1 x 120mm
Front: 1 x 360mm, 1 x 280mm
Top: 1 x 240mm,
Rear: 1 x 120mm
|Clearance||CPU cooler height limitation: 160mm
VGA length limitation: 380mm
PSU length limitation: 170mm
CPU cooler height limitation: 160mm
VGA length limitation: 320mm
PSU length limitation:
160mm (With HDD Rack)
200mm (Without HDD Rack)
